MSM2
MIL-SPEC Monitor (MSM) Series II
On today’s digital battlefield, rugged hardware must be designed to operate in any environment. DSE designs and manufactures highly reliable military COTS displays that meet and exceed key military specifications including MIL-STD-461, MIL-STD-810 and MIL-STD-1275. The MSM2 Series of displays are available in five sizes with a myriad of video input options including DVI-D, VGA, Composite Video (NTSC/PAL), and DisplayPort. MSM2 products can be found supporting missions on vehicles such as THAAD Missile Launcher, Stryker, B1 Bomber, Amphibious Assault Vehicle, C130, and more.
Download Datasheets: by input options:
Download Datasheets: by input options:
Technical Specifications
| Display Sizes | 6.5, 8.4, 10.4, 12.1, 15, and 17″ |
| LCD Resolution | SVGA, XGA, and SXGA |
| Video Inputs | VGA, Composite Video (NTSC/PAL), and/or DVI/DisplayPort |
| Options | Touch Screen, NVIS Compliance/Compatibility, Mounting Configurations |
| Power Input | 10-36VDC |
| Standards | MIL-STD 810, MIL-STD 461, MIL-STD 1275, MIL-STD 704, IP67, DO-160 |
*Specifications may change depending on size and configuration. See data sheet for specific details.
Endless Product Configurations
Size Range
From 6.5” to 17”, the MSM2 series can adapt to most all space claims.
Diverse I/Os
The MSM2 supports everything from Composite Video to VGA, DVI and DisplayPort.
Customization
Color, connectors, size, user interface, firmware, mechanical— let’s modify!
Hard Anodized Aluminum Enclosure
Fully Sealed
Water and dust are no match for the MSM2. These products are sealed to the IP67 standard.
Durable Design
Milled aluminum finished with a hard anodized treatment protects the display from abuse.
Lasting Longevity
The MSM2 series has remained a cornerstone for over one decade— and it isn’t going anywhere.
Trusted by Leading Defense Manufacturers
The MSM212VR was customized as part of BAE Systems’ winning Assault Amphibious Vehicle model for the United States Marines. Discover how DSE is able to modify existing COTS products quickly and cost effectively for our partners.
